+B TRAIL
RBG-A
the safe and robust roll-off trailer
- Maximum security
- Made in ITALY
- EUROPEAN homologation 2007/46/EC
- Container housed inside the rails
- Wheelbase 4200-4900 mm (2-axle version)
- Low maintenance
- No oil leaks
- Low centre of gravity
The MEC +B Trail roll-off trailers RBG-2A and RBG-3A are the result of years of experience and listening to our customers' needs, safety first and foremost.
The container locking system uses 4 internal pneumatic self-aligning clamps to follow any deformation of the container side members.
The absence of hydraulic connection between tractor and trailer reduces maintenance work and eliminates oil leaks. The automatic lowering and raising of the suspension when coupling/uncoupling the trailer facilitates wrapping operations.
The special features of our trailer are:
- the placement of the container inside the frame structure for maximum safety on the road
- separate braking and opening/closing locking systems and locking status controlled by inductive sensors
- automatic braking in the event of even accidental opening of the locks
Main Features
Standard equipment
2 or 3 axles
Air suspension
SAF
Drawbar
lenght 1700 mm
Towing eye
Ø 50 mm
Loading chute
single
Trolley with bilateral load
standard for 3-axle trailer
Internal clamps
4 pneumatic
Rear anti-roll bar
Trolley
in DOMEX with 8 cylinders
Optional
Drawbar lengths from 1300 to 3100 mm
Front anti-roll bar
Central axle lift (for 3-axle version)
Hydraulic clamps
Alloy wheels and chassis galvanisation
Double side box in stainless steel
Model variations
| RBG-A | MTT (ton) | Wheelbase (mm) | Body fitting min (mm) | Body fitting max (mm) |
|---|---|---|---|---|
| RBG-2A | 20 | 4200 / 4900 | 4600 / 5500 | 6500 / 7200 |
| RBG-3A | 26 | 5330 | 5200 | 7200 |
