BS
AIR MAX
The powerful and reliable street sweeper
- Waste container capacity 9 mc gross
- 4 mm thick stainless steel waste container
- Standard water tank capacity 2460 litres
- Standard pneumatic filter grid opening
- Mechanical fan drive with V-belts
- Pneumatic mouth tilt for bulky debris
- Can be mounted on SCANIA 4150 mm wheelbase
BS AIR MAX is an innovative solution for road and pavement sweeping, designed to offer high performance and reliability, guaranteeing efficient and safe cleaning of the environment.
In the BS AIR MAX the brushes made of Ø 700 mm steel wires are driven by an efficient hydraulic motor, and guarantee optimum sweeping even in the most critical situations.
The combination of quality materials, innovative solutions and attention to detail makes the BS AIR MAX the ideal choice for urban sweeping and road resurfacing and construction, helping to keep the streets and surroundings clean and safe.
- The suction fan for extracting debris and dust is made of wear-resistant Hardox 400 steel. Variable speed between 1900 and 3300 rpm allows the performance to be adapted to different operational requirements.
- The suction nozzles, fixed on a trolley towed by super-elastic rubber wheels, are made of Hardox 400 wear-resistant steel to ensure durability.
Main Features
Standard equipment
DEUTZ TCD 3.6 L4 Stage 5 auxiliary engine
Power 55 kW @2200 rpm Maximum torque 500Nm @1600 rpm
Central brush with cylindrical roller Ø 400 mm made of PPL/Steel (OPT Nylon or Nylon/Steel version)
Length 1500 mm, Rotational speed 150 rpm
Water tank 2,200 l, stainless steel
integrated with waste container with internal breakwater
Optional
Simultaneous sweeping strip 3200 mm
Additional, rear-cabin, 2,000-litre stainless steel water tank
1,2,3 Cameras with 7’ LCD monitor
High pressure washing system 15 litres/150 bar complete with hand lance and 12 metre hose reel
80 litre/60 bar high pressure washing system complete with hand lance and 12 metre hose reel
200 mm diameter manual leaf vacuum hose with optional pneumatic support
Additional signal light system
Front brushes
Model variations
| BS AIRMAX | VOLUME (m3) | LENGHT (mm) | WHEELBASE (mm) |
|---|---|---|---|
| BS AIR MAX 9 | 9 | 7345 | 4150 |
